| Brand Name: | Jieshida |
| Model Number: | JSD-B25 |
| MOQ: | 1 SET |
| Price: | USD 200-800 |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T |
The JSD-B25 Kids Swing Turnstile is a safe and intelligent pedestrian access control solution specially designed for preschools, kindergartens, children's activity centers, and educational facilities. Constructed with premium 304 brushed stainless steel, the JSD-B25 combines child-friendly design with reliable security management.
Powered by a DC brushless motor and industrial-grade ARM control system, the turnstile delivers smooth, quiet, and stable operation with a fast 0.5-second opening response and more than 3 million operating cycles. The system supports RFID authentication and optional integrations with face recognition devices, QR code scanners, and fingerprint readers.
Featuring intelligent anti-tailgating detection, automatic reset, anti-collision buffering, and emergency fire alarm integration, the JSD-B25 ensures secure, organized, and efficient child access management for indoor and outdoor educational environments.
The compact structure and smooth swing movement provide safe and comfortable pedestrian access for children and staff.
Supports RFID card authentication and optional integrations with face recognition systems, QR code scanners, and fingerprint devices.
Equipped with a next-generation ARM control system featuring intelligent operation management, digital configuration, and encryption protection.
Provides stable, quiet, and energy-efficient operation with smooth opening and closing performance.
Infrared sensors detect unauthorized following and abnormal intrusion to improve preschool entrance security.
The swing arm automatically returns to the initial position after authorized passage or when no passage occurs within the preset delay time.
Opening and closing speed can be configured according to child safety requirements and pedestrian traffic flow.
The gate activates reverse thrust and buffering protection when abnormal force or accidental impact is detected.
Supports fire alarm signal connection to automatically keep the gate open during emergency evacuation situations.
The swing arm automatically opens during power failure and restores blocking mode after power recovery.
| Product Model | JSD-B25 Kids Swing Turnstile |
| Housing Material | 304 Brushed Stainless Steel |
| Drive Motor | DC Brushless Motor |
| Passage Direction | Single / Bi-directional |
| Opening Time | 0.5 Seconds |
| Passage Width | 550mm |
| Input Voltage | AC220V±10%, 50Hz |
| Working Voltage | DC24V / DC12V |
| Communication Interface | RS485 / Optional TCP/IP |
| Infrared Sensors | 4 Pairs Standard |
| Barrier Material | Acrylic or Stainless Steel |
| Working Temperature | -10°C ~ 60°C |
| Working Environment | Indoor & Outdoor |
| Service Life | Over 3 Million Cycles |
Core Problem Solved: Provides secure child access management and prevents unauthorized entry at school entrances.
Core Problem Solved: Improves visitor and student access organization while maintaining a child-friendly entrance environment.
Core Problem Solved: Enhances attendance tracking and access security for students, teachers, and parents.
Core Problem Solved: Supports safe pedestrian flow control and ticket verification in children's entertainment venues.
Core Problem Solved: Strengthens entrance safety management and improves authorized access control efficiency.
Core Problem Solved: Provides intelligent access management and organized pedestrian flow for student safety.
The JSD-B25 supports RFID card readers and optional integrations with face recognition systems, QR code scanners, fingerprint readers, and ID verification devices.
Yes. The turnstile is specifically designed for children's safety and is ideal for preschools, kindergartens, and childcare centers.
Yes. Built-in infrared sensors detect unauthorized following and automatically trigger alarm notifications.
The swing arm automatically opens during power failure to allow emergency evacuation and free pedestrian passage.
Yes. Multiple speed levels can be configured according to child safety requirements and pedestrian traffic conditions.
Yes. The durable 304 stainless steel structure supports both indoor and outdoor applications.
Standard RS485 communication is supported, with optional TCP/IP networking available for smart management system integration.
The system is designed for more than 3 million continuous opening and closing cycles for long-term stable operation.
